Name: SSH-100kg Load Cell with 6m Cable – Heavy-Duty Sensor for Accurate Load Monitoring and Control
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Load Cell SSH-1t 2.5m
Availability: InStock

Αρχική Σελίδα Προϊόντα

SSH-100kg Load Cell with 6m Cable – Heavy-Duty Sensor for Accurate Load Monitoring and Control

Λεπτομέρειες:

Place of Origin:	CHINA
Μάρκα:	Mettler Toledo
Model Number:	Load Cell SSH-1t 2.5m

Πληρωμής & Αποστολής Όροι:

Minimum Order Quantity:	1 set
Τιμή:	Διαπραγματεύσιμα
Packaging Details:	Caron box
Delivery Time:	10-30days
Supply Ability:	2000 set per month

Επικοινωνία

Λεπτομερής Περιγραφή Προϊόντος

Product:	Mettler Toledo Load Cell	Maximum Capacity:	220 lb (100 kg)
Material:	Stainless Steel	Metrology:	Accuracy 0.02%
Accuracy:	Standard	Protection Rating:	IP68/69k
Platform Size (LxW):	500 mm x 500 mm	Cable:	20 ft (6 m)
Connectivity:	Analog
Επισημαίνω:	SSH-100kg load cell with 6m cable , heavy-duty load cell sensor , accurate load monitoring sensor

SSH-100kg Load Cell with 6m Cable – Heavy-Duty Sensor for Accurate Load Monitoring and Control

A high-performance compression weigh module designed for direct attachment to ground, piers, or structural beams. Ideal for large platform scales including truck and railroad track scales, as well as tank, hopper, and silo weighing applications.

Key Features

High accuracy single point load cell with off-center compensation
Reliable strain gauge technology for long-term durability
Fully welded stainless steel construction
IP68/69k protection rating for harsh environments
Includes 6m (20ft) PVC cable

Technical Specifications

Attribute	Value
Maximum Capacity	220 lb (100 kg)
Material	Stainless Steel
Accuracy	Standard (0.02%)
Protection Rating	IP68/69k
Platform Size	500 mm x 500 mm
Cable Length	6 m (20 ft)
Connectivity	Analog

Wash-Down Applications

The SSH Load Cell's stainless steel construction and IP68/69k rating make it ideal for wash-down environments and harsh industrial conditions, ensuring reliable performance and longevity.
